PROCESSOR

Intel® Core™ i5-10300H Processor

(14nm, 2.5GHz, 8MB Smart Cache, TDP: 45W)

CHIPSET

Mobile Intel® HM470 Express Chipset

DISPLAY

15.6"(39.62cm) FHD (1920x1080)

Matte IPS LED Backlit Display

MEMORY

8GB DDR4 3200MHz RAM

Expandable Memory up to 32GB

GRAPHICS

Intel® UHD Graphics 630

NVIDIA® GeForce MX350

- 2GB GDDR5 Video RAM

- Support PCIe x4

- Microsoft DirectX® 12 compatible

- NVIDIA PhysX®

- GeForce CUDA™ Technology

- Microsoft Hybrid Graphics

- Support 3 active displays

STORAGE

512GB M.2 2280 SSD, NVMe PCIe Gen 3x4 Interface

One changeable 2.5” 7mm(H) HDD / SSD, SATA interface (Optional)

KEYBOARD AND POINTING DEVICE

Multi-Color illuminated full size isolated keyboard with numeric pad

Built-in Click pad with Microsoft PTP multi-gesture and scrolling function

AUDIO

2x2W Speakers

Built in array microphone

Sound Blaster™ Cinema 6

INTERFACE

1 x USB 2.0 port

2 x USB 3.2 Gen 1 ports (Type A)

1 x USB 3.2 Gen 2 port (Type C)

1 x Mini Display port 1.4

1 x HDMI™ output port (with HDCP)

1 x 2-in-1 Audio Jack (Headphone / Microphone)

1 x Microphone Jack

1 x RJ-45 LAN port

1 x DC-in jack

CARD READER

6-in-1 Card reader

MMC / RSMMC

SD / mini SD / SDHC / SDXC

SLOTS

Two M.2 card slots

- 1st for WLAN Combo M.2 2230 Card with PCIe/USB/CNVi interface (E Key)

- 2nd for SSD M.2 2280 Card with SATA / PCIe Gen 3x4 interface (M Key)

COMMUNICATION

Built-in 10/100/1000Mb Base-TX Ethernet LAN

Intel® Dual Band Wireless-AC 9462, 1x1 AC + BT 5

CAMERA

1.0M HD video camera

POWER SUPPLY

Battery

Embedded 4 cells Polymer battery pack, 49WH

Battery life: 500 minutes (UMA mode with 49WH battery) (N.B: Based on testing with MobileMark 2014. Battery life may vary depending on applications and configuration)

Adapter

Full Range AC adapter, AC in 100~240V, 50~60Hz

DC output 19V, 4.74A, 90W

SECURITY

Security (Kensington® Type) Lock Slot

Intel® PTT for the system without Hardware TPM

OPERATING SYSTEM

Windows 10

WEIGHT & DIMENSION

Height: 21.9mm   |   Width: 359.5mm   |   Depth: 238mm   |   Weight: 1.85 kg

IN THE BOX

Laptop Charger

Device Drivers & Utilities

This laptop comes with one year of manufacturer warranty.

Note: This warranty does not cover any damage due to accident, electricity fault, natural causes, or negligence. And Authority keeps the power to change, expand, correct, stop or cancel the warranty period without any prior notice.
