PARAMETER                                                              SRAC-27INVSH

About Model:

Type of AC                                                                  Split

Fixed Speed / Inverter                                                Inverter

Cooling only/ Heating & cooling                                 Cooling only

Product selling area                                                    Bangladesh

Operating Conditions:

Power supply

Rated Voltage & phase                                               230V, Single

Rated frequency                                                         50 Hz

Withstanding Voltage & Frequency                            130V-280V-50HZ

Withstanding Operating conditions: ODU                  20-46°C

Cooling Area                                                               180-240 sq feet

Performance:

Cooling

Capacity (Rated)                                                         7034 Watt

Power (Rated)                                                             2040 Watt

EER(Rated)                                                                 3.44 W/W

Cooling Input Current                                                 8.98 A

Max. Input Power                                                        2550 Watt

Max. Input Current                                                      12.14 A

Motor:

Motor Type: Single Phase Induction                          Wolong, ZWA138D71B (BLDC)

Motors Mechanical output Wattage                            45W

Capacitor                                                                     N/A

Indoor Fan speed (Rated)                                          1180 r/min

Thermal protector                                                       Yes

Indoor Unit Information:

Fan

Dimensions (Dia* Length)                                          Φ108, L- 842±1

Material of Blades                                                       SAN 30% GF

Evaporator

Rows * Tubes                                                              2&18 No's

Tube pitch (a) x row pitch (b)                                      21x12.7 mm

Hairpin copper tube length                                         892 mm

Tube specification                                                       Ø7*0.25+0.18

Tube Material & Grade                                               DHP COPPER, C12200

Fin spacing                                                                 1.2 mm

Fin type                                                                       Louvered

Fin Material                                                                 Al (Golden coated)

Other:

Filter Type                                                                   Mesh Filter

Power cord & Plug                                                      Yes, 1.5 Meter

Connecting wire between IDU & ODU: Length          3.5 Meter

Compressor:

Preferred Model                                                          GKT208MAC

Type: Fixed speed / Inverter                                       Inverter

Inverter Frequency Range: Min to Max                      10-130 Hz

Locked rotor Amp (LRA)                                             N/A

Over load Protector (Location)                                   N/A

Capacitor (If applicable)                                              N/A

Fan motor

Motor Type: Single Phase Induction                           Wolong, YYW55-6-7273

Motors Mechanical output Wattage                            55W

Capacitor                                                                     4 uF

Outdoor Fan speed                                                     850 R/min

or Unit Information:

Thermal protector                                                       Yes

Fan

Dimensions (Dia* Hight)                                             Φ420, H-133

Number of Blades                                                       4 No's

Material of Blades                                                       ABS 20%GF

Other

Gas/ Refrigerant Type                                                R-410a

Gas/ Refrigerant Qty                                                   0.83 KG
