PARAMETER                                                              SRAC-20INVSH

About Model:

Type of AC:                                                                 Split

Fixed Speed / Inverter                                                Inverter

Cooling only/ Heating & cooling                                 Cooling only

Product selling                                                            Bangladesh

Operating Conditions:

Power supply

Rated Voltage & phase                                               230V, Single

Rated frequency                                                         50 Hz

Withstanding Voltage & Frequency                            130V-280V-50HZ

Withstanding Operating conditions: ODU                  20-46°C

Cooling Area                                                               120-180 sq feet

Performance:

Cooling

Capacity (Rated)                                                         5275 Watt

Power (Rated)                                                             1740 Watt

EER(Rated)                                                                 3.03 W/W

Cooling Input Current                                                 7.6 A

Max. Input Power                                                        2180 Watt

Max. Input Current                                                      9.6 A

Motor:

Motor Type: Single Phase Induction                           Wolong, YYW35-4-5200A

Motors Mechanical output Wattage                            35 W

Capacitor                                                                     2.0 uF

Indoor Fan speed (Rated)                                          1160 r/min

Thermal protector                                                       Yes

Indoor Unit Information:

Fan

Dimensions (Dia* Length)                                          Φ108 mm, L- 704±1

Material of Blades                                                       SAN 30% GF

Evaporator:

Rows * Tubes                                                              2*16 No's

Tube pitch (a) x row pitch (b)                                      21x12.7 mm

Hairpin copper tube length                                         749 mm

Tube specification                                                       Ø7*0.25 + 0.18 mm

Tube Material & Grade                                               DHP COPPER, C12200

Fin spacing                                                                 1.2 mm

Fin type                                                                       Louvered

Fin Material                                                                 Al (Golden coated)

Other:

Filter Type                                                                   Mesh Filter

Power cord & Plug                                                      Yes, 1.5 Meter

Connecting wire between IDU & ODU: Length          3.5 Meter

Compressor:

Preferred Model                                                          KSN133D21UFZ(GMCC)

Type: Fixed speed / Inverter                                       Inverter

Inverter Frequency Range: Min to Max                      10-120 Hz

Locked rotor Amp (LRA)                                             N/A

Overload Protector (Location)                                    N/A

Capacitor (If applicable)                                              N/A

Fan motor:

Motor Type: Single Phase Induction                           Wolong, YYW35-6-7287

Motors Mechanical output Wattage                            35 W

Capacitor                                                                     3.0 uF

Outdoor Fan speed                                                     880 R/min

or Unit Information:

Thermal protector                                                       Yes

Fan

Dimensions (Dia* Hight)                                             Φ400 mm, H-115

Number of Blades                                                       3 No's

Material of Blades                                                       ABS 20%GF

Condenser:

Rows*Tubes                                                                2*26 No's

Tube pitch(a)x row pitch(b)                                         19.5*11.6 mm

Hairpin Copper tube length                                        810/480 mm

Tube specification                                                       Ø5*0.20 + 0.15 mm

Tube Material & Grade                                               DHP COPPER, C12200

Fin spacing                                                                 1.1 mm

Fin Type                                                                      Slit

Fin Material                                                                 Al (Golden coated)

Other:

Gas/ Refrigerant Type                                                R32

Gas/ Refrigerant Qty                                                   0.66 KG
