Model Name                                                   RSDC-12RTSI

Type                                                                Cooling only

Control type                                                    Remote

Power supply                                                  1Ph-220-240V~50Hz

Voltage Range                                                198~242 V

Cooling:

Capacity                                                          12000(2730~12500) Btu/h

Capacity                                                          3200(800~3665) W

Rated power Input                                          1053(250~1450) W

Rated current                                                  4.9(1.2~7.5) A

EER                                                                 3.04 W/W

Max power Input                                             1450 W

Max current                                                     7.5 A

Indoor coil

a. Number of rows                                          2

b. Tube pitch(a)x row pitch(b)                         21×12.7 mm

c. Fin spacing                                                 1.5 mm

e. Tube outside dia and type                          Φ7 mm, innergroove tube

f. Coil length x height x width                          /

g. Number of circuits                                       1 in 2 out

Outdoor coil:

a. Number of rows                                          1

b. Tube pitch(a)x row pitch(b)                         19.5×11.6 mm

c. Fin spacing                                                  1.2 mm

e. Tube outside dia and type                          Φ5 mm, innergroove tube

f. Coil length x height x width                          /

g. Number of circuits                                       1 in 1 out

Indoor unit:

Dimension(W*D*H)                                         776×250×202 mm

Packing (W*D*H)                                            850×320×275 mm

Net/Gross weight                                            8/10 Kg

Outdoor unit:

Dimension(W*D*H)                                         787×290×498 mm

Packing (W*D*H)                                            818×325×520 mm

Net/Gross weight                                            22/26 Kg

Pressure:

High (DP)                                                        4.5 MPa

Low (SP)                                                         1.9 MPa

Refrigerant                                                      R410A/0.53kg

Ambient temperature                                      -15~50℃

Suitable area                                                   15~23 m2

Connecting Wiring

Size x Core number                                        4×1.0mm²×5.8m

Power supply cord                                          AWG16

Qty 40'HQ                                                       310
