PARAMETER                                                              SRAC-15INVSH

About Model:

Type of AC                                                                  Split, Inverter, Cooling only

Product selling area                                                    Bangladesh.

Operating Conditions                                                  Power supply

Rated Voltage & phase                                               230V, Single

Rated frequency                                                         50 Hz

Withstanding Voltage & Frequency                            130V-280V-50HZ

Withstanding Operating conditions: ODU                  20-46°C

Cooling Area                                                               90-120 sq feet

Performance:

Cooling

Capacity (Rated)                                                         3517 Watt

Power (Rated)                                                             1120 Watt

EER(Rated)                                                                 3.14 W/W

Cooling Input Current                                                 4.86 A

Max. Input Power                                                        1380 Watt

Max. Input Current                                                      7 A

Motor

Motor Type: Single Phase Induction                          Wolong, YYW25-4-5201L

Motors Mechanical output Wattage                            25 W

Capacitor                                                                     1.5 uF

Indoor Fan speed (Rated)                                          1200 r/min

Thermal protector                                                       Yes

Indoor Unit Information:

Fan

Dimensions (Dia* Length)                                          Φ97 mm, L- 649±1

Material of Blades                                                       SAN 30% GF

Evaporator

Rows * Tubes                                                              2*12 No's

Tube pitch (a) x row pitch (b)                                      21x12.7 mm

Hairpin copper tube length                                         691 mm

Tube specification                                                       Ф7x0.25+0.18 mm

Tube Material & Grade                                               DHP COPPER, C12200

Fin spacing                                                                 1.2 mm

Fin type                                                                       Louvered

Fin Material                                                                 Al (Golden coated)

Other

Filter Type                                                                   Mesh Filter

Power cord & Plug                                                      Yes, 1.5 Meter

Connecting wire between IDU & ODU: Length          3.5 Meter

Compressor

Preferred Model                                                          KSK89D35UEZ3(GMCC)

Type: Fixed speed / Inverter                                       Inverter

Inverter Frequency Range: Min to Max                      10-120 Hz

Locked rotor Amp (LRA)                                             N/A

Overload Protector (Location)                                    N/A

Capacitor (If applicable)                                              N/A

Fan motor

Motor Type: Single Phase Induction                           Wolong, YYW25-6-17045L

Motors Mechanical output Wattage                            25 W

Capacitor                                                                     2.5 uF

Outdoor Fan speed                                                     850 R/min

Thermal protector                                                       Yes

Fan

Dimensions (Dia* Hight)                                             Φ400 mm, H-115

Number of Blades                                                       3 No's

Material of Blades                                                       ABS 20%GF

Condenser

Rows*Tubes                                                                1*12 No's

Tube pitch(a)x row pitch(b)                                         19.5*11.6 mm

Hairpin Copper tube length                                        820 mm

Tube specification                                                       Ф5x0.20+0.15 mm

Tube Material & Grade                                               Copper, Inner grove

Fin spacing                                                                 1.1 mm

Fin Type                                                                      Slit

Fin Material                                                                 Al (Golden coated)

Other

Gas/ Refrigerant Type                                                R32

Gas/ Refrigerant Qty                                                   0.42 KG
