TECHNICAL SPECIFICATIONS

Performance

• Cooling Capacity: 10,000 W

• Heating Capacity: 11,000 W

• Rated Input Power (Cooling): 3,550 W

• Rated Input Power (Heating): 3,225 W

• Air Circulation: 1,800 m³/h

• Energy Efficiency Ratio (EER – Cooling): 2.82 W/W

• Coefficient of Performance (COP – Heating): 3.41 W/W

• Energy Efficiency Class: B

Electrical Data

• Power Supply: 220–240 V ~ / 1 Phase / 50 Hz

• Rated Current (Cooling): 6.0 A

• Rated Current (Heating): 5.7 A

Noise Level

• Indoor Unit Noise Level (High / Medium / Low): 50 / 47 / 44 dB(A)

Compressor & Refrigeration System

• Compressor Type: Rotary

• Compressor Model: ATH420UC-C9EU

• Compressor Manufacturer: Highly

• Expansion Device: Throttle

Heat Exchangers

• Evaporator: Copper Tube with Aluminum Fin

• Condenser: Copper Tube with Aluminum Fin

Physical Specifications

• Panel Dimensions (W × H × D): 950 × 37 × 950 mm

• Indoor Unit Dimensions (W × H × D): 840 × 248 × 840 mm

• Panel Net Weight: 6 kg

• Indoor Unit Net Weight: 30 kg
