Basic Features:

Function                                                          Cooling

BTU/hr                                                             24000

Rated Voltage                                                 230V ~ 50Hz

Rated Input Power (W)                                   2280

Rated Current (A)                                           10.70

Cooling Capacity (W)                                     7034

EER                                                                 3.08

Cooling Features:

Compressor Type                                           Rotary (Fixed Speed)

Refrigerant Type                                             R-410a

Refrigerant Amount (kg)                                 1.480

Operating Range (Ambient Temperature)      20˚C to 43˚C

Evaporator Fin Type                                       Louvered Fin

Condenser Type                                             Copper Tube Condenser

Condenser Fin Type                                       Slit Fin

Maximum Pipe Length                                    15m

Operations:

Turbo Mode (Maximum Cooling)                    Yes

ECO Mode (Power Saving)                            No

Dry Mode                                                        Yes

Fan Mood                                                        Yes

Auto Operation                                                Yes

Auto Restart                                                    Yes

Comfort Cooling                                              Yes

Speed Setting                                                 Yes (Auto, High, Medium, Low)

Timer                                                               Yes

Sleep                                                               Yes

Air Deflection:

Auto UP-Down Swing                                     Yes

Auto Left-Right Swing                                     Yes

Remote:

Display Type                                                   LCD

Operation/Control                                            Via IR (Infrared Ray)

Child Lock                                                       Yes

Temperature Unit Change                              Yes (16​°C to 31°C)

Dimensions:

Indoor Dimensions (mm) [L×W×H]                 Unit: 1093 x 329 x 243

Packing:                                                          1180 x 410 x 315

Outdoor Dimensions (mm) [L×W×H]              Unit: 865 x 370 x 687

Packing:                                                          935 x 435 x 750

Weights:

Net Weight (Indoor) (Kg)                                17 ± 0.5

Gross Weight (Indoor) (Kg)                            19 ± 0.5

Net Weight (Outdoor) (Kg)                             46 ± 1

Gross Weight (outdoor) (Kg)                          52 ± 1
