Basic Features:

Function                                                          Heating & Cooling

BTU/hr                                                             12000

Rated Voltage                                                 230V~50Hz

Cooling:

Rated Current (A)                                           5.4

Rated Capacity (W)                                        3517

Rated Input Power (W)                                   1210

EER                                                                 2.91

Cooling & Operating Range                           20˚C to 43˚C

Heating:

Rated Current (A)                                           5.1

Rated Capacity (W)                                        3517

Rated Input Power (W)                                   1120

COP                                                                3.14

Heating & Operating Range                           –7˚C to 24˚C

Heating & Cooling Features:

Compressor Type                                           Rotary (Fixed Speed)

Refrigerant Type                                             R-410a

Refrigerant Amount (Kg)                                 0.73

Indoor Heat Exchanger Fin Type                    Louvered Fin

Outdoor Heat Exchanger Tube Type              Slit Fin

Indoor Heat Exchanger Tube Type                Copper Tube

Maximum Pipe Length                                    10m

Operations:

Turbo Mode                                                     Yes

Auto Operation                                                Yes

Dry Mode                                                        Yes (Cooling Mode Only)

Fan Mode                                                        Yes

Speed Setting                                                 Yes (Auto, High, Medium, Low)

Auto Restart                                                    Yes

Comfort Cooling                                              Yes

Timer                                                               Yes

Sleep                                                               Yes

Air Deflection:

Auto UP-Down Swing                                     Yes

Auto Left-Right Swing                                     Yes

Remote:

Display Type                                                   LCD

Operation/Control                                            Via IR (Infrared Ray)

Child Lock                                                       Yes

Temperature Unit Change                              Yes

Dimensions:

Indoor Dimensions (mm) [L×W×H]                 Unit: 844 x 296 x 210

Packing: 910 x 365 x 285

Outdoor Dimensions (mm) [L×W×H]              Unit: 844 x 310 x 546

Packing:                                                          900 x 372 x 610

Weights:

Net Weight (Indoor) (Kg)                                11±0.5

Gross Weight (Indoor) (Kg)                            13±0.5

Net Weight (Outdoor) (Kg)                             29.8±1

Gross Weight (outdoor) (Kg)                          33.7±1
