Basic Features:

Function                                                          Cooling

BTU/hr                                                             12000

Rated Voltage                                                 230V ~ 50Hz

Rated Input Power (W)                                   1260

Rated Current (A)                                           5.6

Cooling Capacity (W)                                     3517

EER                                                                 2.8

Cooling Features:

Compressor Type                                           Rotary (Fixed Speed)

Refrigerant Type                                             R-410a

Refrigerant Amount (kg)                                 0.7

Operating Range (Ambient Temperature)      20˚C to 43˚C

Evaporator Fin Type                                       Louvered Fin

Condenser Type                                             Copper Tube Condenser

Condenser Fin Type                                       Slit Fin

Maximum Pipe Length                                    10m

Operations:

Turbo Mode (Maximum Cooling)                    Yes

ECO Mode (Power Saving)                            No

Dry Mode                                                        Yes

Fan Mood                                                        Yes

Auto Operation                                                Yes

Auto Restart                                                    Yes

Comfort Cooling                                              Yes

Speed Setting                                                 Yes (Auto, High, Medium, Low)

Timer                                                               Yes

Sleep                                                               Yes

Air Deflection:

Auto UP-Down Swing                                     Yes

Auto Left-Right Swing                                     Yes

Remote:

Display Type                                                   LCD

Operation/Control                                            Via IR (Infrared Ray)

Child Lock                                                       Yes

Temperature Unit Change                              Yes

Dimensions:

Indoor Dimensions (mm) [L×W×H]                 Unit: 844 x 296 x 210

Packing:                                                          910 x 365 x 285

Outdoor Dimensions (mm) [L×W×H]              Unit: 721 x 320 x 552

Packing:                                                          825 x 365 x 630

Weights:

Net Weight (Indoor) (Kg)                                11±0.5

Gross Weight (Indoor) (Kg)                            13±0.5

Net Weight (Outdoor) (Kg)                             28±1

Gross Weight (outdoor) (Kg)                          32±1
