Basic Features

• Function: Cooling

• Cooling Capacity: 18,000 BTU/hr

• Rated Voltage: 230V ~ 50Hz

• Rated Input Power: 1885 W

• Rated Current: 8.25 A

• Cooling Capacity (W): 5,275 W

• Energy Efficiency Ratio (EER): 2.8

Cooling System

• Compressor Type: Rotary (Fixed Speed)

• Refrigerant Type: R-410A

• Refrigerant Charge: 1.0 kg

• Operating Ambient Temperature: 20°C to 43°C

• Evaporator Fin Type: Louvered Fin

• Condenser Type: Copper Tube Condenser

• Condenser Fin Type: Slit Fin

• Maximum Pipe Length: 10 m

Operating Modes & Functions

• Turbo Mode (Maximum Cooling): Yes

• ECO Mode (Power Saving): No

• Dry Mode: Yes

• Fan Mode: Yes

• Auto Operation: Yes

• Auto Restart: Yes

• Comfort Cooling: Yes

• Fan Speed Settings: Auto / High / Medium / Low

• Timer: Yes

• Sleep Mode: Yes

Airflow Control

• Auto Up-Down Swing: Yes

• Auto Left-Right Swing: Yes

Remote Control

• Display Type: LCD

• Control Method: Infrared (IR)

• Child Lock: Yes

• Temperature Adjustment Range: 16°C – 31°C

Dimensions (L × W × H)

Indoor Unit

• Unit: 933 × 321 × 230 mm

• Packing: 1010 × 380 × 290 mm

Outdoor Unit

• Unit: 721 × 320 × 552 mm

• Packing: 825 × 365 × 630 mm

Weight

Indoor Unit

• Net Weight: 12.5 ± 0.5 kg

• Gross Weight: 15 ± 0.5 kg

Outdoor Unit

• Net Weight: 35 ± 1 kg

• Gross Weight: 38 ± 1 kg
