Basic Features:

Function:                                                         Cooling

BTU/hr :                                                           12000

Rated Voltage:                                                230V ~ 50Hz

Rated Input Power (W):                                  1260

Rated Current (A):                                          5.6

Cooling Capacity (W):                                    3517

EER:                                                                2.8

Cooling Features:

Compressor Type:                                          Rotary (Fixed Speed)

Refrigerant Type:                                            R-410a

Refrigerant Amount (kg):                                0.7

Operating Range (Ambient Temperature):     20˚C to 43˚C

Evaporator Fin Type:                                      Louvered Fin

Condenser Type:                                            Copper Tube Condenser

Condenser Fin Type:                                      Slit Fin

Maximum Pipe Length:                                   10m

Operations:

Turbo Mode (Maximum Cooling):                   Yes

ECO Mode (Power Saving):                           No

Dry Mode:                                                       Yes

Fan Mood:                                                       Yes

Auto Operation:                                               Yes

Auto Restart:                                                   Yes

Comfort Cooling:                                             Yes

Speed Setting:                                                Yes (Auto, High, Medium, Low)

Timer:                                                              Yes

Sleep:                                                              Yes

Air Deflection:

Auto UP-Down Swing:                                    Yes

Auto Left-Right Swing:                                    Yes

Remote:

Display Type:                                                  LCD

Operation/Control:                                           Via IR (Infrared Ray)

Child Lock:                                                      Yes

Temperature Unit Change:                             Yes

Dimensions:

Indoor Dimensions (mm) [L×W×H]                 Unit: 832 x 296 x 210

Packing:                                                          910 x 365 x 285

Outdoor Dimensions (mm) [L×W×H]              Unit: 721 x 320 x 552

Packing:                                                          825 x 365 x 630

Weights:

Net Weight (Indoor) (Kg):                               10.7 ± 0.5

Gross Weight (Indoor) (Kg):                           12.85 ± 0.5

Net Weight (Outdoor) (Kg):                            26.10 ± 1

Gross Weight (outdoor) (Kg):                         29.90 ± 1
