Basic Features

Function                                                  Cooling

BTU/hr                                                   18000

Rated Voltage                                         230V ~ 50Hz

Rated Input Power (W)                             1510

Rated Current (A)                                    6.6

Cooling Capacity (W)                               5275

EER                                                      3.5

Cooling Features

Compressor Type                                     Rotary (Inverter)

Refrigerant Type                                       R-410a

Refrigerant Amount (kg)                             1.2

Operating Range (Ambient Temperature)      20˚C to 52˚C

Evaporator Fin Type                                   Louvered Fin

Condenser Type                                       Copper Tube Condenser

Condenser Fin Type                                 Slit Fin

Maximum Pipe Length                                10m

Operations

Turbo Mode (Maximum Cooling)                 Yes

ECO Mode (Power Saving)                       Yes

Dry Mode                                               Yes

Fan Mood                                                Yes

Auto Operation                                          Yes

Auto Restart                                            Yes

Comfort Cooling                                        Yes

Speed Setting                                         Yes (Auto, High, Medium, Low)

Timer                                                     Yes

Sleep                                                      Yes

Air Deflection

Auto UP-Down Swing                                 Yes

Auto Left-Right Swing                               Yes

Remote

Display Type                                           LCD

Operation/Control                                      Via IR (Infrared Ray)

Child Lock                                               Yes

Temperature Unit Change                          Yes (16​°C to 31°C)

Dimensions

Indoor Dimensions (mm) [L×W×H]               Unit: 947 x 321 x 232

Packing:                                                 1025 x 400 x 300

Outdoor Dimensions (mm) [L×W×H]             Unit: 865 x 370 x 687

Packing:                                                 935 x 435 x 750

Weights

Net Weight (Indoor) (Kg)                             12.5 ± 0.5

Gross Weight (Indoor) (Kg)                          15 ± 0.5

Net Weight (Outdoor) (Kg)                           37 ± 1

Gross Weight (outdoor) (Kg)                      42 ± 1
