Basic Features

• Function: Cooling

• Cooling Capacity: 18,000 BTU/hr

• Rated Voltage: 230V ~ 50Hz

• Rated Input Power:

  • Version 0608: 1,570 W

  • Version 0611: 1,710 W

• Rated Current:

  • Version 0608: 6.82 A

  • Version 0611: 7.57 A

• Cooling Capacity (W): 5,275 W

• Energy Efficiency Ratio (EER):

  • Version 0608: 3.35

  • Version 0611: 3.08

Cooling System

• Compressor Type: Rotary (Inverter)

• Refrigerant Type:

  • Version 0608: R-32

  • Version 0611: R-410A

• Refrigerant Charge:

  • Version 0608: 0.92 kg

  • Version 0611: 1.16 kg

• Operating Ambient Temperature Range: 20°C – 52°C

• Evaporator Fin Type: Louvered Fin

• Condenser Type: Copper Tube Condenser

• Condenser Fin Type: Slit Fin

• Maximum Pipe Length: 10 m

Operating Modes & Functions

• Turbo Mode (Maximum Cooling): Yes

• ECO Mode (Power Saving): Yes

• Dry Mode: Yes

• Fan Mode: Yes

• Auto Operation: Yes

• Auto Restart: Yes

• Comfort Cooling: Yes

• Fan Speed Settings: Auto / High / Medium / Low

• Timer Function: Yes

• Sleep Mode: Yes

Airflow Control

• Auto Vertical Swing (Up-Down): Yes

• Auto Horizontal Swing (Left-Right): Yes

Remote Control

• Display Type: LCD

• Control Method: Infrared (IR)

• Child Lock: Yes

• Temperature Adjustment Range: 16°C – 31°C

Dimensions (L × W × H)

Indoor Unit

• Unit Size: 942 × 321 × 238 mm

• Packing Size: 1,025 × 400 × 300 mm

Outdoor Unit

• Unit Size: 844 × 310 × 546 mm

• Packing Size: 900 × 372 × 610 mm

Weight

Indoor Unit

• Net Weight: 12.5 ± 0.5 kg

• Gross Weight: 15 ± 0.5 kg

Outdoor Unit

• Net Weight:

  • Version 0608: 26.5 ± 1 kg

  • Version 0611: 29 ± 1 kg

• Gross Weight:

  • Version 0608: 31 ± 1 kg

  • Version 0611: 33 ± 1 kg
