Product Description

Cooling System

• Type: Direct Cool

Capacity & Weight

• Gross Volume: 358 Liters

• Net Volume: 345 Liters

• Net Weight: 76.5 ± 2 kg

• Gross Weight: 84 ± 2 kg

Performance

• Climate Class: N ~ ST

• Rated Voltage / Frequency / Power: 220–240 V / 50 Hz / 135 W

Compressor Details

• Input Power:

  • Version V0102: 130 W

  • Version V0301: 123 W

• Compressor Type:

  • Version V0102: RSCR

  • Version V0301: RSCR

Cooling Performance

• Freezer Compartment: Below −18°C

• Refrigerator Compartment: 0°C to +5°C

General Features

• Temperature Control: Mechanical

• Defrosting: Manual

• Reversible Door: No

• Handle Type: Recessed

• Door Lock: Yes

Eco-Friendly Technology

• Refrigerant: R600a

• Thermostat: RoHS Certified

• Capillary Tube: Copper

• Foam Blowing Agent: Cyclopentane

• Green Technology: 100% CFC & HCFC Free

Voltage Stabilizer Requirement

• Stabilizer Required: Not required under normal conditions

• Recommended Stabilizer: 2100 VA (if voltage is outside 140V–260V range)

Refrigerator Compartment Features

• Shelves: 2 × Wire Shelves

• Door Baskets: 3

• Interior Lamp: Yes

• Vegetable Crisper: 1

• Vegetable Crisper Cover: Yes

• Egg Tray / Pocket: Yes

• Can Storage Dispenser: No

• Deodorizer: No

Freezer Compartment Features

• Shelf Type: Rack Evaporator

• Drawers: 4

• Ice Tray: 1

• Ice Case: 2

• Ice Remover Spoon: 1

• Door Basket: No

• Interior Lamp: No

Dimensions

Net Dimensions

• Width: 594 mm

• Depth: 711 mm

• Height: 1820 mm

Packaging Dimensions

• Width: 625 mm

• Depth: 745 mm

• Height: 1830 mm

Container Loading Capacity

• 40 HQ: 76 Units

• 40 Ft: 57 Units

• 20 Ft: 27 Units

Warranty Information

Residential Use

• Replacement Guarantee: 1 Year (Conditions Apply)

• Compressor Warranty: 12 Years

• Door Warranty: 3 Years*

• Spare Parts Warranty: 4 Years*

• After-Sales Service: 5 Years*

Commercial Use

• Compressor Warranty: 4 Years

• Door Warranty: 1 Year*

• Spare Parts Warranty: 2 Years*

• After-Sales Service: 2 Years*

Warranty Exclusions

This warranty does not cover:

1. Damage caused by accidents, electrical faults, natural disasters, negligence, or improper installation.

2. Damage or malfunction due to unauthorized modification or alteration.

3. Products with removed, altered, or unidentifiable original serial numbers.
