Model                                                              EV-24RINV

Type                                                                Split

Control type                                                    Cooling Inverter

Power supply                                                  1Ph-220-240V~50Hz

Voltage Range                                                155~265 V

Capacity                                                          24000(4094~25590) Btu/h

Capacity                                                          7034(1200~7500) W

Rated power Input                                          2198(300~2450) W

Rated current                                                  9.9(1.4~13.0) A

Max power Input                                             2450 W

Max current                                                     13 A

Compressor:

Model                                                              ATN150042UFZ

Type                                                                Rotary

Brand                                                              GMCC

Compressor type                                            T1

Capacity                                                          15286 Btu/h

Input                                                                1120 W

Rated current (RLA)                                       7.75 A

Locked rotor Amp (LRA)                                 /

Capacitor                                                         /

Refrigerant oi/oil charge                                 ESTEL OI VG74-450 ml

Indoor unit:

Dimension(W*D*H)

Packing (W*D*H)                                            1165x405x295 mm

Outdoor unit:

Dimension(W*D*H)                                         920x380x699 mm

Packing (W*D*H)                                            960x430x732 mm

Pressure:

High (DP)                                                        4.5 MPa

Low (SP)                                                         1.9 MPa

Refrigerant                                                      R410A

Ambient temperature                                      0~43℃
