Model Name                                       KSV-24TPINV-SW

Type                                                    Cooling only

Control type                                        Remote

Power supply                                      208-230V~/50Hz/1P

Voltage Range                                    165~265 V

Cooling:

Capacity                                              24000(4090~24900) Btu/h

Capacity                                              7035(1200~7300) W

Rated power Input                              2185(300~2800) W

Rated current                                      10.1(2.5~13.5) A

EER                                                     3.22 W/W

Max power Input                                 2800 W

Max current                                         13.5 A

Indoor coil:

a. Number of rows                              2

b. Tube pitch(a)x row pitch(b)             21×12.7 mm

c. Fin spacing                                     1.4 mm

e. Tube outside dia and type              Φ7 mm, innergroove tube

F. Coil length x height x width             /

g. Number of circuits                           4 in 4 out

Outdoor coil:

a. Number of rows                              2

b. Tube pitch(a)x row pitch(b)             19.5×11.6 mm

c. Fin spacing                                     1.2 mm

e. Tube outside dia and type              Φ5 mm, inner groove tube

f. Coil length x height x width             /

g. Number of circuits                           3 in 3 out

Indoor unit:

Dimension(W*D*H)                             1010×315×220 mm

Packing (W*D*H)                                1096×390×297 mm

Net/Gross weight                                13/16 Kg

Outdoor unit:

Dimension(W*D*H)                             853×349×602 mm

Packing (W*D*H)                                890×385×628 mm

Net/Gross weight                                30/35 Kg

Refrigerant piping:

Liquid side/ Gas side                          φ6(1/4")/φ12(1/2") mm(inch)

Max. refrigerant pipe length               15 m

Max. difference in level                       5 m

Pressure:

High (DP)                                            4.5 MPa

Low (SP)                                             1.9 MPa

Refrigerant                                          R410A/990g

Ambient temperature                          -15~50℃

Suitable area                                       30~50 m2

Connecting Wiring

Size x Core number                            4×0.75mm2

Power supply cord                              3×1.5mm²
