Walton-WCF-1D5-RRXX-XX

Main Features:

• Type: Direct Cool
• Category: Frost
• Gross Volume: 146 Ltr
• Net Volume: 146 Ltr
• Refrigerant: R600a

Full Specifications

Cooling Features :

• Type: Direct Cool

Capacity :

• Gross Volume:146 Ltr.
• Net Volume: 146 Ltr.

Performance :

• Climatic Type (SN, N, ST, T): N ~ ST
• Rated Operating Voltage and Frequency: 220 ~ 240/ 50
• Compressor Input Power (Watt):
•            V 03.01- 110
•            V 04.01- 111
•            V 05.01- 140
• Compressor Type:
•           V 03.01- RSCR
•           V 04.01- RSCR
•           V 05.01- RSCR
• Cooling Effect: Freezer Cabinet Less than -18℃
• Energy Rating: N/A

General Features:

• Temperature Control (Electronic/ Mechanical): Mechanical
• Defrosting (Automatic/ Manual): Manual
• Reversible Door: Foaming Door
• Handle (Recessed/ Grip): N/A
• Lock: N/A
• Refrigerant
•          V 03.01- R134a
•          V 04.01- R134a
•          V 05.01- R600a
• Condenser: 100% Copper
• Thermostat: RoHS Certified
• Capillary: Copper
• Polyurethane foam blowing agent: CycloPentane[Eco-friendly (100% CFC &HCFC Free) Green Technology]
• Recommended voltage stabilizer capacity (600VA):
•        V 01.01
•        V 02.01
•        V 03.01
•        V 04.01
•        V 05.01

Freezer Compartment :

• Exterior Material: Painted Steel (PCM)
• Interior Material: Embossed Aluminium Sheet
• Ice/ cold water Dispenser: No
• Shelf (Material/No): Wire/1
• Drawer: No
• Basket: Wire/1
• Interior Lamp: No

Dimensions (Net) :

• Width/mm: 743
• Depth/mm: 574
• Height/mm: 823

Packing :

1. Width/mm: 760
2. Depth/mm: 600
3. Height/mm: 865
4. Weight/Kg - Net/Packing:: 35 / 39 ± 2
5. Loading Capacity- 40HQ/ 40Ft/ 20Ft: 180/ 120/ 60
